- **Chassis**: Reinforced Dongfeng Tianjin chassis (China VI/Euro 6)
- **Capacity**: 19.8m³ with dual-cylinder compression system (faster loading)
- **Powertrain**: High-power engine (300+ HP) for long-distance heavy-duty transport
- **Chassis**: Reinforced Dongfeng Tianjin chassis (China VI/Euro 6)
- **Capacity**: 19.8m³ with dual-cylinder compression system (faster loading)
- **Powertrain**: High-power engine (300+ HP) for long-distance heavy-duty transport
- **Smart Upgrade**: Optional IoT system for real-time monitoring
- **Durability**: High-strength steel body + anti-corrosion coating (30% longer lifespan)
|
Vehicle Model |
HYZ5181ZDJDF |
|
Chassis Model |
Dongfeng DFH1180EX8 |
|
Engine Model |
B6.2NS6B210 D6.7NS6B230 |
|
Engine Power (kW) |
154.169 |
|
Engine Displacement |
6200.6700 |
|
Fuel Type |
Diesel |
|
External Dimensions (mm) |
8000,7800x2550x3250mm |
|
Gross Mass (kg) |
18000 |
|
Curb Weight (kg) |
8500 |
|
Rated Load Capacity (kg) |
9370.9305 |
|
Box Volume (cbm) |
19.8 |
|
Approach/Departure Angles |
17/14 |
|
Front/Rear Overhang |
1400/1900,1430/1870 |
|
Wheelbase (mm) |
3800,3950,4200,4500,4700,5000,5300,5800 |
|
Maximum Speed (km/h) |
90 |
|
Tire Size |
10.00R20 18PR,275/80R22.5 18PR |
|
Unloading Cycle Time |
60s |
|
Emission Standards |
Euro 6(5/4/3) |
|
Dock Height (mm) |
1470 |
**Large-scale waste management facilities
**Municipal heavy-duty collection
**Airports/ports with high sanitation standards
